Lenovo SR670 Specification
Form factor: 2U rack
Chipset: Intel C624 "Lewisburg" chipset
Processor: Two second-generation Intel Xeon Processor Scalable processors (formerly codename "Cascade Lake"). Up to 28 cores, core frequencies up to 3.8 GHz, and TDP ratings up to 205W. Two Intel Ultra Path Interconnect (UPI) links at 10.4 GT/s each
Memory: 24 DIMM sockets (12 DIMMs per processor) supporting Lenovo TruDDR4 DIMMs at up to 2933 MHz
Power supply: Two 2000W hot-swap AC power supplies with 80 PLUS Platinum certification. Power supplies are redundant in most configurations. Requires 200-240 V AC power (110 V AC not supported).
Cooling: Six N+1 redundant simple-swap 60 mm dual-rotor fans (all six standard). One fan integrated in each power supply.
Ports: Front: One USB 2.0 port, one USB 3.0 port, one VGA video port, one RJ45 XClarity Controller (XCC) systems management port. Rear: One DB9 serial port. The serial port can be redirected and accessed remotely via IPMI or SSH via XCC.
Network Interfaces: None standard; add networking via a PCIe adapter. Dedicated Ethernet port for systems management (connected to the XClarity Controller) is standard.
Dimensions: width: 448 mm (17.6 in.), height: 87 mm (3.4 in.), depth: 906 mm (35.7 in.)
Weight: 32 kg (71.9 lb) depending on the specific configuration.
