Chipset: Intel C606 Chipset
Processor: Up to two Intel® Xeon® E5-2400 series processors, Intel Xeon E5-2403 processor (4C/4T, 1.8GHz, 10MB, 6.4 GT/s QPI x1), 3-channel DDR3 memory controller (up to 1066MHz) Intel Xeon E5-2407 processor (4C/4T, 2.2GHz, 10MB, 6.4 GT/s QPI x1), 3-channel DDR3 memory controller (up to 1066MHz) Intel Xeon E5-2420 processor (6C/12T, 1.9GHz, 15MB, 7.2 GT/s QPI x1), Turbo Boost 2.0 (up to 2.4GHz), 3-channel DDR3 memory controller (up to 1333MHz) Intel Xeon E5-2450 processor (8C/16T, 2.1GHz, 20MB, 8.0 GT/s QPI x1), Turbo Boost 2.0 (up to 2.9GHz), 3-channel DDR3 memory controller (up to 1600MHz)
Memory: UDIMM, RDIMM or LV RDIMM, DDR3, ECC, 3-channel per processor, 240-pin, 12 DIMM sockets (6 sockets per processor); 192GB max (RDIMM/LV RDIMM, 12x16GB) or 48GB max (UDIMM, 12x4GB)
RAID support: Up to RAID 0, 1, 5, 6, 10, 50, 60 via ThinkServer RAID 700 adapter
Disk Bays: Up to 4 x 3.5-inch SATA/SAS; Up to 8 x 2.5-inch SATA/SAS
Network Interface: 2 x Integrated Gb Ethernet; 1 x Integrated Gb Ethernet (Dedicated to ThinkServer System Manager)
Power Supply: 2x 550W (80 PLUS Gold) 110V to 240V AC input
