Form factor: 2U rack-mount
Chipset: Intel C610 Series
Processor: up to two processors of the Intel Xeon processor E5-2600 v4 product family: up to 22 cores (2.2 GHz core speeds), up to 3.5 GHz core speeds (4 cores), two QPI links up to 9.6 GT/s each, up to 55 MB cache, up to 2400 MHz memory speed
Memory: Up to 24 DIMM sockets (12 DIMMs per processor; four memory channels per processor with three DIMMs per channel). Support for RDIMMs and LRDIMMs. Memory types cannot be intermixed. Memory speed up to 2400 MHz
Maximum memory capacity: With RDIMMs: up to 768 GB with 24x 32 GB RDIMMs and two processors, with LRDIMMs: Up to 1.5 TB with 24x 64 GB LRDIMMs and two processors
Network interfaces: one AnyFabric slot for optional AnyFabric adapters: dual-port 10 GbE RJ-45, dual-port 10 GbE SFP+, quad-port 10 GbE SFP+, quad-port GbE RJ-45
Ports: front (2.5-inch chassis only): 2x USB 2.0 ports, 1x VGA port (DB-15), rear: 2x USB 3.0 ports, 1x VGA port (DB-9), 1x RJ-45 GbE management port for TSM. Optional serial port (DB-9)
Power supply: up to two redundant hot-swap 550 W, 750 W, 1100 W, or 1600 W* 100-240 V AC Platinum power supplies or 750 W 200-240 V AC Titanium power supplies.
Dimensions: height: 87 mm (3.4 in.), width: 447 mm (17.6 in.), depth: 764 mm (29.4 in.)
Weight: minimum: 16 kg (35.3 lb), maximum: 32 kg (70.5 lb)
