Lenovo ST650 v2 Specifications
Form Factor: 4U rackable tower
Processors: Up to 2x 3rd generation Intel® Xeon® Scalable processors, up to 250W
Drive Bays: Up to 32x 2.5" bays (including 16 NVMe bays) or 16x 3.5" bays (including 8 NVMe bays)
Memory: Up to 4TB in 32x DIMM slots using 128GB DIMMs; 3200MHz TruDDR4; Up to 16x Intel® Optane™ Persistent Memory 200 Series module (PMem), installed in combination with system memory DIMMs
Expansion Slots: Up to 8x PCIe 4.0 slots plus 1x PCIe 3.1 slot (with 2x processors)
Network Interface: 2x 10GBASE-T ports; 1x 1GbE dedicated management port
HBA/RAID Support: SW RAID standard; optional HW RAID up to 32 ports, or SAS HBAs up to 16 ports
Power: Dual redundant AC power supplies (750W, 1100W, 1800W, 2400W) Platinum and Titanium. Energy Star 3.0 compliant.
Dimensions: Width: 175 mm (6.9 in.), height: 462 mm (18.2 in.), depth: 734 mm (28.9 in.)
Weight: 2.5-inch configuration: 39.28 kg (86.60 lb) maximum 3.5 -inch configuration: 46.23 kg (101.92 lb) maximum
