Lenovo ST250 v2 Specifications
Form Factor: 4U chassis
Chipset: Intel C256 chipset ("Tiger Lake") part of the "Tatlow" platform
Processor: 1x Intel® Xeon® processor E-2300 or 1x Intel® Pentium® processor, up to 8 cores at 95W
Memory: Up to 128GB in 4x DIMM slots using 32GB UDIMMs 3200MHz TruDDR4
Expansion Slots: Slot 1: PCIe x4 slot with PCIe Gen3 x4 lanes
Slot 2: PCIe x16 slot with PCIe Gen4 x16 lanes
Slot 3: PCIe x4 slot with PCIe Gen3 x4 lanes
Slot 4: PCIe x8 slot with PCIe Gen3 x4 lanes
Network Interface: 2x GbE on-board ports (Broadcom BCM5720); 1x GbE port dedicated for XCC management
HBA/RAID Support: Intel® VROC Software RAID support with both simple-swap and hot-swap configuration; multiple hardware RAID configurations supported
Power Supplies: Model dependent choices
One fixed 250W power supply: 80 PLUS Platinum certified, ErP Lot 9 compliant
One fixed 300W power supply: 80 PLUS Gold certified
Two hot-swap 550W redundant power supplies, 80 PLUS Platinum certified, Energy Star and ErP Lot 9 compliant.
