HP Integrity rx6600 Server

HP rx6600 Specifications

Processor Configuration: The HP Integrity rx6600 is a Symmetrical Multi-Processing (SMP) server supporting up to four high performance 64 bit Dual-Core Intel Itanium processors. The Dual-Core Intel Itanium processor supports hyper threading. Each core of the processor supports two threads.

Processor board:

Processor cores: 2 - 8

Processor modules: 1 - 4

Chipset: HP zx2

System bus bandwidth: 8.5 GB/s

System memory: The HP Integrity rx6600 supports Dual Data Rate (DDR2) Synchronous Dynamic Random Access Memory (SDRAM) Dual In-line Memory Modules (DIMMs) with ECC and double chip spare protection. The HP Integrity rx6600 can be ordered with one of the following two memory carrier boards:

AD126A-Supports from 2GB minimum to 96GB maximum memory; 8.5 GB/s memory bandwidth. The AD126A can be replaced with the AD127A to increase maximum memory beyond 96GB and to a maximum of 192GB, or to increase memory bandwidth to 17.0 GB/s. There is no return credit for the AD126A.

AD127A-Supports from 2GB minimum to 384GB maximum memory; 17.0 GB/s memory bandwidth.

Memory slots: 24 or 48 DIMM slots (Depending on user choice of memory board)

Internal storage devices:

Internal hard disk drive bays: 16 Hot-Plug Serial Attached SCSI (SAS) Small Form Factor (SFF) 2.5-inch drives

Disk offerings: 36GB, 73GB Maximum storage: 1.2TB with 73GB drives

Removable media: 1 open bay for DVD-ROM or DVD+RW

Storage adapter: HPE 8-port Serial Attached SCSI (SAS) Host Bus Adapter (HBA) with RAID 1 (HP-UX and OpenVMS); HPE 8-port SAS Smart Array adapter upgrade with RAID 1, 5, 6 (Windows and Linux)
