HP rx3600 Specifications
Processor Configuration: The HP Integrity rx3600 is a symmetrical multiprocessing (SMP) server supporting up to two high performance 64 bit dual core Intel Itanium processors. The dual core Intel Itanium processor supports hyper threading. Each core of the processor supports two threads.
Processor board:
Processor cores: 2-4
Chipset: HP zx2
System bus bandwidth: 8.5 GB/s
Dual-core processor modules:
Dual core Intel Itanium 2 processors:
1.66 GHz with 18 MB Level 3 Cache, 9 MB per core 9140M processor
1.42 GHz with 12 MB Level 3 Cache, 6 MB per core 9120N processor
All processors support:
Level 1 Cache: 32 KB
Level 2 Cache: 1 MB Instruction/256 KB Data per core
Level 3 cache: 12 MB per processor at 1.42 GHz; 18 MB per processor at 1.66 GHz
Four threads (two threads per core)
Single bit cache error correction
50 bit physical addressing
64 bit virtual addressing
4 GB maximum page size
Power requirements:
Maximum input current: 15 A @ 100 VAC
Line frequency: 50–60 Hz
Maximum AC power input: 1,194 W
Power supply: Maximum output 1200 W
